GeoPro injection systems

Technical resin systems for challenging ground conditions.

Explore specialist injection systems for soil strengthening, rock support, groundwater control, ground consolidation and controlled void filling.

Explore the product range Request selection guidance
Product 01 / Void filling

GeoPro SF-25

Controlled void-filling injection system

An injection resin system intended for controlled void filling and ground treatment where expansion and distribution through accessible subsurface spaces are required.

Typical applications

  • Subsurface void filling
  • Treatment around buried structures
  • Accessible cavities and spaces
  • Loose or disturbed ground zones
  • Controlled material expansion
  • Localised ground stabilisation

Selection considerations Assess the size and accessibility of the void, surrounding confinement, moisture conditions, required expansion and the potential for material to migrate beyond the intended treatment area.

Download SF-25 data sheet Enquire about SF-25

See GeoPro SF-25 in application

Watch the product video to learn more about its placement, expansion and intended ground-treatment applications.

Product video
GeoPro injection systems SF-25 product video
01 / Application Controlled void filling
02 / Placement Targeted resin injection
03 / Objective Ground stabilisation
GeoPro injection systems SP-16 product video
01 / Application Ground permeation
02 / Placement Targeted resin injection
03 / Objective Ground strengthening
Product 02 / Rock stabilisation

GeoPro SP-16

Polyurethane-silicate material for rock stabilisation

GeoPro SP-16 is a polyurea-silicate injection material designed for rock support and consolidating fractured or unstable rock formations.

Typical applications

  • Rock support
  • Consolidation of gravel zones/li>
  • Stabilisation of unstable rock formations
  • Reducing hydraulic conductivity
  • Underground construction
  • Mining and tunnelling applications

Selection considerations Assess the rock condition, fracture pattern, injection arrangement and required stabilisation outcome. Confirm product suitability and application parameters against the GeoPro SP-16 technical data sheet and project-specific requirements.

Download SP-16 data sheet Enquire about SP-16
/* =======================================================
Product 03 / Lower-flow water control

GeoPro LF-10

Lower-flow water-control injection system

GeoPro LF-10 is an injection system intended for controlled treatment of lower-flow groundwater pathways, localised seepage and connected ground features where manageable placement and reaction characteristics are required.

Typical applications

  • Lower-flow groundwater pathways
  • Localised seepage treatment
  • Restricted ground features
  • Connected fractures and joints
  • Targeted water-control works
  • Treatment near sensitive areas

Selection considerations Establish the rate of water movement, pathway dimensions, connectivity, groundwater pressure and the time available for placement before reaction. Confirm suitability against the current technical data sheet before use.

Download LF-10 data sheet Enquire about LF-10
GeoPro injection systems LF-10 product video
01 / Conditions Lower-flow groundwater pathways
02 / Placement Controlled resin injection
03 / Objective Localised water control
GeoPro Injection Systems

GeoPro HF-45

GeoPro injection systems HF-45 product video
01 / Reaction Rapid reacting
02 / Application Two-component injection
03 / Primary use Water cut-off
HF-45

Rapid-reacting water cut-off injection system

GeoPro HF-45 is a rapid-reacting, two-component injection system intended for water cut-off applications.

Typical applications

  • Control of active water ingress
  • Injection into water-bearing gravels
  • Water cut-off in underground structures
  • Remedial injection in mining, tunnelling and civil engineering works

Selection considerations

Selection and injection planning should consider the water flow rate, leakage path, injection requirements and the condition of the surrounding substrate. Refer to the current technical data sheet before use.

Download data sheet Make an enquiry
Product 05 / Low-viscosity injection

GeoPro LV-20

Low-viscosity ground-injection system

A low-viscosity injection system designed to move through fine fissures, narrow pathways and permeable ground. GeoPro LV-20 supports controlled resin distribution where deeper or broader penetration is required within the treatment zone.

Typical applications

  • Fine fissures and narrow pathways
  • Permeable soils and granular ground
  • Ground beneath slabs and foundations
  • Localised soil consolidation
  • Water-pathway treatment
  • Controlled subsurface injection

Selection considerations Review soil permeability, moisture conditions, injection spacing, anticipated resin migration and the required treatment radius. Injection pressure and volume should be controlled to keep the resin within the intended treatment zone.

Download LV-20 data sheet Enquire about LV-20
GeoPro injection systems LV-20 product video
01 / Viscosity Low-viscosity formulation
02 / Distribution Controlled ground penetration
03 / Treatment Fine-pathway injection
GeoPro injection systems AC-5 product video
01 / Material Acrylic injection resin
02 / Property Ultra-low viscosity
03 / Primary use Fine-soil permeation and water control
Product 06 / Ultra-low-viscosity acrylic resin

GeoPro AC-5

Acrylic injection resin for permeation and water control

GeoPro AC-5 is an ultra-low-viscosity acrylic injection resin developed for permeation grouting into fine soils and for water control within fissures and soils. Its low viscosity supports penetration into fine pore structures and narrow pathways where effective resin distribution is required.

Typical applications

  • Permeation grouting into fine soils
  • Water control within soils
  • Injection into fissures and narrow pathways
  • Groundwater ingress control
  • Sealing around below-ground structures
  • Remedial water-control injection

Selection considerations Review the soil grading and permeability, fissure or pathway characteristics, groundwater conditions and required treatment extent. Injection spacing, pressure and resin delivery should be controlled to achieve effective permeation while limiting movement beyond the intended treatment zone.

Download AC-5 data sheet Enquire about AC-5
Product 07 / Ultra-low-viscosity colloidal silica

GeoPro CS-5

Colloidal silica resin for permeation and fissure grouting

GeoPro CS-5 is an ultra-low-viscosity colloidal silica injection resin designed for permeation grouting and fissure grouting. It penetrates fine soil pore structures and narrow rock fractures, helping to consolidate soils and control water movement through soils and fractured rock.

Typical applications

  • Permeation grouting in fine soils
  • Consolidation of loose and granular soils
  • Fissure grouting in fractured rock
  • Water control through soils
  • Water control through rock fractures
  • Reduction of ground and fracture permeability

Selection considerations Assess the soil grading and permeability, the size and continuity of rock fractures, groundwater conditions and the required treatment extent. Injection pressure, flow rate, spacing and material delivery should be controlled to achieve effective permeation while limiting movement beyond the intended treatment zone.

Download CS-5 data sheet Enquire about CS-5

Video coming soon

Our GeoPro CS-5 product video will be available soon.

Product video
GeoPro injection systems CS-5 product video
01 / Material Colloidal silica injection resin
02 / Property Ultra-low viscosity
03 / Primary use Soil consolidation and water control
Technical support

Not sure which GeoPro system is right for your project?

Every injection project presents different ground conditions, treatment objectives and access constraints. Speak with our team about your application and we will help you identify the most appropriate GeoPro injection system for further assessment.

Discuss your project Review product range
01 / Review Tell us about the project

Provide the available site details, treatment objectives and supporting information.

02 / Assess Consider the application

The project conditions and injection requirements can then be reviewed in more detail.

03 / Select Identify a suitable system

Determine which GeoPro product should be considered for the proposed treatment.
